Scissor Lift - S120-D23-L
Technical datas
| Manufacturer name: | Haulotte H12SXL |
| Max. working height: | 12 m |
| Max. platform height: | 10 m |
| Max. Lift capacity: | 700 kg |
| platform size: | 5,30 x 1,89 m |
| platform extended: | 7,30 x 1,89 m |
| Transport dimensions: | 5,30 x 2,28 m |
| Transportation height: | 2,59 m |
| Height with railing folded down: | 1,75 m |
| Weight: | 5700 kg |
| ground preasure tyres: | 3420 daN |
| Ground pressure load support max.: | 2740 daN |
| Power: | diesel |
| Gradeability: | 40 % |
Features
| Levelling: | yes |
| Usage area: | outdoor use |
| All-terrain mobility: | yes |
Special features
+ Very high load capacity
+ Automatic support levelling
+ Mega platform (7,30 m) with extension on both sides
+ All-wheel drive
+ Black foam-filled tires
+ Railing with plug system
