PC18.0t-E

add to my request

Technical datas

Type:JMG MC180S
Lifting height max.:15 m*
Capacity max.:18000 kg
Horizontal reach:10,50 m*
Load capacity at max. lifting height:3000 kg*
Load capacity at max. range/reach:2000 kg*
Transport dimensions:5,45 x 1,96 m**
Power:electro
Machine height:2 m
Weight:21610 kg***
Ground pressure max. (Front axle):32500 daN

Features

Support frames:yes
Non marking tires:yes

Special features

- Remote control with load display
- Removable counterweights 6110 kg


Attachments (optional):
- load hook max. 18000 kg
- hydraulic mounting tip max. 7000 kg
- Mounting tip max. 13000 kg
- Cable winch 16000 kg






* Depending on the attachments
** Transport length without attachment
*** Machine weight with full ballast, without attachment
